Description:
Anti-static polyimide tape is antistatic, heat resistance, moisture resistance, easy to tear off, no glue left on surface, meet ROHS, ideal for use in circuit board production, wave soldering, solder dip, or electrical applications where static is an issue.
Features
* Film: Polyester
* Glue: Thermal resistance and sillicone adhesive
* Surface resistance: 105~108Ω
* Glue surface resistance: 109~1010Ω
* Surfaces low-tribocharge(50V) at 50% RH
* Heat resistance: 180°C for 30mins, 200°C for 10mins
* Total thickness: 0.04mm, 0.06mm, 0.08mm, 0.11mm
* Widths: 10, 20, 30, 40, 50, 500（mm）
* Roll length: 33m
* Plastic core, inner diameter: 76mm
* Color: Green
Storage:
* Tapes should be stored in a dry, well ventilated room with a reasonably consistent temperature of 20°C and be protected from exposure to direct sunlight.
* Tape should not be stored in ultraviolet sunlight, moisture, or heat.
* Tape over one year old should be evaluated by the user to determine acceptability for the user’s application.
