Floor marking tape

Click to zoom in

Description:

This self-adhesive, high visibility floor marking PVC tape is suitable for marking the boundaries of ESD Protected Areas. It is waterproof, moisture resistant, non-corrosive, and adheres very well to concrete floors, wooden floor, ceramic tile, marble floor, wall and machine, and can be expected to remain intact for several months depending on traffic.

Features

* Film: PVC
* Glue: Silicon pressure sensitive adhesive
* Total thickness: 0.12mm, 0.15mm, 0.18mm, other thickness are on request.
* Width: 45,48,50,60 (mm), length: 10,13,15,16,17,20,22,25,33(m), other sizes are on request.
* Color: Blue, White, Green, Black, Red, Yellow, Red+White, Black+White, Green+White, Yellow+Black…
* The tape is not antistatic as it is intended for use outside the ESD protection area
* Storage:
* Tapes should be stored in a dry, well ventilated room with a reasonably consistent temperature of 20°C and be protected from exposure to direct sunlight.
* Tape should not be stored in ultraviolet sunlight, moisture, or heat.
* Tape over one year old should be evaluated by the user to determine acceptability for the user’s application.

Description:

Code Color W x L Thickness Peeling force Tensile strength Elongation rate Max temperature
CL9166 Yellow/Red… 45/48/50/60mmx33m 0.18mm 1.8 N/cm 26N/cm 160% 60°C
