Description:
ESD Shielding Bags are made of a multi-layer 3mil (0.075mm) or 5.5mil (0.14mm) laminated film which has a metal layer as its core. This layer functions as a barrier to E.S.D which allows a charge to move around and not through the bag. The inner layer provides static dissipative protection for the metal layer and also strengthens seal of bag. The outer layer is a non-static generating layer that resists abrasion and puncture.
Features
* Material: APET/CPE
* The surface resistance: 108~1011
* Available in open flat, self-sealed.
* Sizes are on request.
* Thickness: regular 3mil, 5.5mil, other thickness are on request.
* Sealing: two sides or three sides
* Edge: 5mm, or 10mm according to bag size.
* Opening: at long side, or open at short side
* Packing: 100pcs/bag, or 200pcs/bag
* It is suitable for packing of PCB, IC and other static sensitive components
* This kind of hot seal bag is transparent, so the goods inside can be easily recognized from outside.
* Physical property meet the ASTMD257, ELA541 and MIL-B-81705 international standards
